SANY Turntable GP
What is the SANY Turntable GP
- The SANY Turntable GP is a comprehensive rotational platform system engineered to deliver exceptional stability, precision, and reliability in heavy machinery operations. Central to this assembly is the robust Weldment GP, turntable, which forms the foundational structure supporting rotational movement and load distribution. The system integrates critical mechanisms such as the Swing mechanism for smooth 360-degree rotation and the Hoisting mechanism for controlled lifting operations, ensuring seamless coordination during complex tasks.
- Key components include the Rope, wire, main winch and Rope, wire, auxiliary winch, which are securely fastened with Clamp, rope elements to prevent slippage and ensure safe load management. The turntable locking bolt STC250S5.2.13 provides additional security by immobilizing the turntable during maintenance or stationary operations. For enhanced visibility, the Mirror GP, rear-view, turntable offers operators a clear field of vision, improving safety during maneuvering.
- The Counterweight AS and 3-hinge-point assem STC250S5.2.10 work in tandem to balance dynamic loads and optimize stability. Precision alignment is achieved through components like the Shaft, pin, Clamp pin, and spacer sleeve STC250S.2.10-4, while the shaft guard plate STC250S5.2-3 and Sleeve, wedge protect against wear and misalignment. The Cylinder, luffing enables precise boom angle adjustments, contributing to overall operational accuracy.
- The Engine shed houses essential power systems, and all elements are securely assembled with high-strength Bolt fasteners, Washer components, and Wedge fittings to ensure vibration-resistant durability. Designed for demanding environments, the SANY Turntable GP exemplifies engineering excellence, combining advanced functionality with rugged construction to maximize performance, safety, and longevity in industrial applications. This system underscores SANY’s commitment to innovation and quality in heavy machinery design.
Parameters of SANY Turntable GP
| Item No. | Part No. | Description | Qty. |
| 1 | A219900000075 | Clamp, rope | 2 |
| 2 | 11210734 | Rope, wire, main winch | 1 |
| 3 | 12822590 | turntable locking boltSTC250S5.2.13 | 1 |
| 4 | 10123663 | Mirror GP, rear-view, turntable | 1 |
| 5 | 11117463 | Counterweight AS | 1 |
| 6 | 12822492 | 3-hinge-point assemSTC250S5.2.10 | 1 |
| 7 | 11072931 | Swing mechanism | 1 |
| 8 | 11074232 | Hoisting mechanism | 1 |
| 9 | 11079343 | Engine shed | 1 |
| 10 | 11241580 | Weldment GP, turntable | 1 |
| 11 | A210401000006 | Washer | 2 |
| 12 | A219900000128 | Wedge | 2 |
| 13 | 11210735 | Rope, wire, auxiliary winch | 1 |
| 14 | A210508000139 | Shaft, pin | 2 |
| 15 | A210111000367 | Bolt | 2 |
| 16 | A820209990021 | Clamp pin | 2 |
| 17 | 10138483 | Shaft, pin | 1 |
| 18 | 12822450 | shaft guard plateSTC250S5.2-3 | 1 |
| 19 | 10517054 | Cylinder, luffing | 1 |
| 20 | 12330701 | spacer sleeveSTC250S.2.10-4 | 2 |
| 21 | A219900000129 | Sleeve, wedge | 2 |
