SANY Planetarygp
What is the SANY Planetarygp
- The SANY PLANETARYGP represents one-third of the complete planetary gear system that forms the heart of SANY’s advanced transmission technology. This sophisticated subassembly features a comprehensive CARRIER-PLANET that houses multiple GEAR-PLANET components, each rotating on precision SHAFT and SHAFTAS-PLANET assemblies with BEARING-RLR and BEARING-SPL bearings for smooth operation. The system incorporates multiple clutch elements including PLATE-CLUTCH plates and DISC-FRICTION friction discs, all working in conjunction with PISTON actuators that utilize RING-SEAL(INT) and RING-SSAL(EXT) seals for perfect hydraulic operation.
- The SANY PLANETARYGP includes vital thrust management through DISC-THRUST washers and BEARING-THRUST bearings, while the GEAR-RING provides the stationary outer gear interface. The assembly incorporates numerous retention components such as RING-RETAINING rings and RING-LOCK locking rings, along with PIN and PIN-SPRING elements that work with SPRING components to maintain proper clutch pack tension. Sealing is ensured through SEAL-O-RINGO and SEAL-LIPTYPE seals, with GASKET-REARHSG gaskets providing additional sealing surfaces.
- The SANY PLANETARYGP is housed within a precision HOUSING and connects to the CASEAS-XMSN transmission case, featuring ROTOR-OUTPUT for power delivery and CARRIER-BEARING support for the GEAR-SUN central gear. Fastening is achieved through BOLT-HEXHEAD bolts with WASHER-HARD and standard Washer components, while PLUG-LDSTOR plugs with SEAL-O-RING-STORO seals provide maintenance access points. The meticulous engineering of the SANY PLANETARYGP ensures optimal power distribution, exceptional durability, and reliable performance in the most demanding operating conditions, reflecting SANY’s commitment to transmission excellence.
Parameters of SANY PLANETARYGP (1/3)
| No. | Part No. | Description | Qty |
| 1 | 130202000093A061 | GASKET-REARHSG | 1 |
| 2 | 130202000093A062 | RING-SEAL(EXT) | 1 |
| 3 | 130202000093A063 | PISTON | 1 |
| 4 | 130202000093A064 | RING-SEAL(INT) | 1 |
| 5 | 130202000093A065 | RING-RETAINING | 1 |
| 6 | 130202000093A066 | BEARINGAS | 1 |
| 7 | 130202000093A038 | Washer | 20 |
| 8 | 130202000093A067 | BOLT-HEXHEAD | 19 |
| 9 | 130202000093A068 | HOUSING | 1 |
| 10 | 130202000093A069 | ROTOR-OUTPUT | 1 |
| 11 | 130202000093A070 | PLUG-LDSTOR | 2 |
| 12 | 130202000093A071 | SEAL-O-RINGO | 3 |
| 13 | 130202000093A016 | SEAL-LIPTYPE | 1 |
| 14 | 130202000093A072 | PLUG-LDSTOR | 6 |
| 15 | 130202000093A011 | SEAL-O-RING-STORO | 6 |
| 16 | 130202000093A073 | CARRIER-PLANET | 1 |
| 17 | 130202000093A074 | BEARING-RLR | 2 |
| 18 | 130202000093A075 | SHAFT | 1 |
| 19 | 130202000093A076 | GEAR-PLANET | 4 |
| 20 | 130202000093A077 | BEARING-SPL | 4 |
| 21 | 130202000093A078 | SHAFTAS-PLANET | 4 |
| 22 | 130202000093A079 | DISC-THRUST | 8 |
| 23 | 130202000093A080 | GEAR-RING | 1 |
| 24 | 130202000093A081 | PLATE-CLUTCH | 2 |
| 25 | 130202000093A082 | PLATE-CLUTCH | 12 |
| 26 | 130202000093A083 | DISC-FRICTION | 18 |
| 27 | 130202000093A084 | BEARING-THRUST | 2 |
| 28 | 130202000093A085 | SPRING | 4 |
| 29 | 130202000093A086 | PIN | 4 |
| 30 | 130202000093A087 | PLATE-CLUTCH | 4 |
| 31 | 130202000093A088 | PIN | 8 |
| 32 | 130202000093A089 | SPRING | 8 |
| 33 | 130202000093A090 | GEAR-RING | 1 |
| 34 | 130202000093A091 | RING-SEAL(INT) | 2 |
| 35 | 130202000093A092 | PISTON | 2 |
| 36 | 130202000093A093 | RING-SEAL(EXT) | 2 |
| 37 | 130202000093A094 | SEAL-O-RINGO | 2 |
| 38 | 130202000093A341 | SEAL-O-RINGO | 3 |
| 39 | 130202000093A095 | BOLT-HEXHEAD | 1 |
| 40 | 130202000093A344 | WASHER-HARD | 1 |
| 41 | 130202000093A096 | BOLT-HEXHEAD | 1 |
| 42 | 130202000093A097 | PLUG-LDSTOR | 1 |
| 43 | 130202000093A098 | CASEAS-XMSN | 1 |
| 44 | 130202000093A099 | RING-LOCK | 2 |
| 45 | 130202000093A100 | CARRIER-PLANET | 1 |
| 46 | 130202000093A101 | RING-RETAINING | 1 |
| 47 | 130202000093A102 | PLATE-CLUTCH | 1 |
| 48 | 130202000093A103 | PIN-SPRING | 14 |
| 49 | 130202000093A104 | SHAFTAS.-PLANET | 4 |
| 50 | 130202000093A105 | BEARING | 4 |
| 51 | 130202000093A106 | GEAR-PLANET | 4 |
| 52 | 130202000093A107 | DISC-THRUST | 8 |
| 53 | 130202000093A108 | BEARING-THRUST | 2 |
| 54 | 130202000093A109 | SHAFT-CENTER | 1 |
| 55 | 130202000093A110 | CARRIER-BEARING | 1 |
| 56 | 130202000093A111 | GEAR-SUN | 1 |
| 57 | 130202000093A112 | RING-RETAINING | 1 |
Parameters of SANY PLANETARYGP (2/3)
| No. | Part No. | Description | Qty |
| 25 | 130202000093A082 | PLATE-CLUTCH | 12 |
| 26 | 130202000093A083 | DISC-FRICTION | 18 |
| 27 | 130202000093A084 | BEARING-THRUST | 2 |
| 30 | 130202000093A087 | PLATE-CLUTCH | 4 |
| 31 | 130202000093A088 | PIN | 8 |
| 32 | 130202000093A089 | SPRING | 8 |
| 34 | 130202000093A091 | RING-SEAL(INT) | 2 |
| 35 | 130202000093A092 | PISTON | 2 |
| 36 | 130202000093A093 | RING-SEAL(EXT) | 2 |
| 44 | 130202000093A099 | RING-LOCK | 2 |
| 48 | 130202000093A103 | PIN-SPRING | 14 |
| 58 | 130202000093A113 | SPRING-WAVE | 1 |
| 59 | 130202000093A114 | COUPLING | 1 |
| 60 | 130202000093A115 | CARRIERAS | 1 |
| 61 | 130202000093A116 | DISC-THRUST | 12 |
| 62 | 130202000093A117 | BEARING-RLRAS | 12 |
| 63 | 130202000093A118 | GEAR-PLANET | 6 |
| 64 | 130202000093A119 | SHAFTAS.-PLANET | 6 |
| 65 | 130202000093A120 | DISC-THRUST | 1 |
| 66 | 130202000093A121 | HUBAS | 1 |
| 67 | 130202000093A122 | SEAL-O-RINGO | 1 |
| 68 | 130202000093A123 | CONE-TAPEREDRLR | 1 |
| 69 | 130202000093A124 | CUP-TAPEREDRLR | 1 |
| 70 | 130202000093A125 | SEAL-O-RINGO | 1 |
| 71 | 130202000093A126 | SEAL-O-RINGO | 1 |
| 72 | 130202000093A127 | HOUSING-SEAL | 1 |
| 73 | 130202000093A128 | SCREW-TRUSSHEA M8X1.25 | 6 |
| 74 | 130202000093A129 | RING-METALSEAL | 1 |
| 75 | 130202000093A130 | RING-SEAL | 2 |
| 76 | 130202000093A131 | HUB | 1 |
| 77 | 130202000093A132 | SEAL-ORINGO | 1 |
| 78 | 130202000093A133 | PLATE-CLUTCH | 3 |
| 79 | 130202000093A134 | RING-SEAL | 1 |
| 80 | 130202000093A135 | PLATE-CLUTCH | 1 |
| 81 | 130202000093A136 | BEARING-NEEDLE | 1 |
| 82 | 130202000093A137 | RING-LOCK | 1 |
| 83 | 130202000093A138 | DISC-THRUST | 1 |
| 84 | 130202000093A139 | RING-SEAL(EXT) | 1 |
| 85 | 130202000093A140 | PISTON | 1 |
| 86 | 130202000093A141 | SPRING-CONED | 1 |
| 87 | 130202000093A142 | PISTON | 1 |
| 88 | 130202000093A143 | RING-SEAL(EXT) | 1 |
| 89 | 130202000093A144 | SCREW-TRUSSHEAD | 12 |
| 90 | 130202000093A145 | GEAR-SUN | 1 |
| 91 | 130202000093A328 | BEARING-THRUST | 1 |
| 92 | 130202000093A146 | WASHER-HARD | 8 |
| 93 | 130202000093A147 | BOLT | 8 |
| 94 | 130202000093A148 | MANIFOLDAS. | 1 |
Parameters of SANY PLANETARYGP (3/3)
| No. | Part No. | Description | Qty |
| 17 | 130202000093A074 | BEARING-RLR | 2 |
| 53 | 130202000093A108 | BEARING-THRUST | 2 |
| 91 | 130202000093A328 | BEARING-THRUST | 1 |
| 95 | 130202000093A149 | SHAFTAS | 1 |
| 96 | 130202000093A150 | SEAL-ORINGO | 1 |
| 97 | 130202000093A151 | RING-SEAL | 1 |
| 98 | 130202000093A152 | RING-SEAL(EXT) | 1 |
| 99 | 130202000093A153 | PISTON | 1 |
| 100 | 130202000093A154 | SPRING-WAVE | 1 |
| 101 | 130202000093A155 | RING-SPACER | 1 |
| 102 | 130202000093A156 | RING-RETAINING | 1 |
| 103 | 130202000093A157 | HUB-CLUTCH | 1 |
| 104 | 130202000093A158 | RING-RETAINING | 1 |
| 105 | 130202000093A159 | PLATE-CLUTCH | 5 |
| 106 | 130202000093A160 | DISC-FRICTION | 5 |
| 107 | 130202000093A161 | PLATE-REACTION | 1 |
| 108 | 130202000093A162 | RING-RETAINING | 1 |
| 109 | 130202000093A329 | GASKET | 1 |
| 110 | 130202000093A163 | BEARING-INNER | 1 |
| 111 | 130202000093A164 | RING-SEAL | 4 |
| No. | Part No. | Description | Qty |
| 17 | 130202000093A074 | BEARING-RLR | 2 |
| 53 | 130202000093A108 | BEARING-THRUST | 2 |
| 91 | 130202000093A328 | BEARING-THRUST | 1 |
| 95 | 130202000093A149 | SHAFTAS | 1 |
| 96 | 130202000093A150 | SEAL-ORINGO | 1 |
| 97 | 130202000093A151 | RING-SEAL | 1 |
| 98 | 130202000093A152 | RING-SEAL(EXT) | 1 |
| 99 | 130202000093A153 | PISTON | 1 |
| 100 | 130202000093A154 | SPRING-WAVE | 1 |
| 101 | 130202000093A155 | RING-SPACER | 1 |
| 102 | 130202000093A156 | RING-RETAINING | 1 |
| 103 | 130202000093A157 | HUB-CLUTCH | 1 |
| 104 | 130202000093A158 | RING-RETAINING | 1 |
| 105 | 130202000093A159 | PLATE-CLUTCH | 5 |
| 106 | 130202000093A160 | DISC-FRICTION | 5 |
| 107 | 130202000093A161 | PLATE-REACTION | 1 |
| 108 | 130202000093A162 | RING-RETAINING | 1 |
| 109 | 130202000093A329 | GASKET | 1 |
| 110 | 130202000093A163 | BEARING-INNER | 1 |
| 111 | 130202000093A164 | RING-SEAL | 4 |
