SANY Tcgp-Basic
What is the SANY Tcgp-Basic
- The SANY TCGP-BASIC represents the fundamental torque converter assembly that forms the heart of SANY’s transmission system, engineered for exceptional power transfer efficiency and durability. This sophisticated assembly integrates numerous precision components including the IMPELLER and TURBINE which work in harmony to convert and multiply engine torque through hydraulic fluid dynamics. The system is secured with multiple fastening elements such as BOLT-SOCKETHEAD, BOLT-HEXHEAD, and BOLT-HEXSOCKET components, along with Washer and WASHER-HARD elements for vibration-resistant connections.
- The SANY TCGP-BASIC incorporates advanced sealing technology through components like SEAL-O-RINGO, RING-SEAL, and RING-SEALMETAL that ensure perfect fluid containment. The assembly features critical bearing surfaces with BEARING-THRUST and RACE-BRGTHRUST components that manage axial loads, while the CARRIER-STATOR and STATOR-CONVERTER provide stationary reaction elements for torque multiplication. The SANY TCGP-BASIC also includes the HUB-IMPELLER and HUB-TURBINE for power transmission, along with DOWEL pins for precise alignment.
- The clutch system within the SANY TCGP-BASIC consists of PISTON-CLUTCH, DISC-FRICTION, and PLATE-BACKING elements, while the freewheel mechanism employs CAM-FREEWHEEL, ROLLER-FREEWHEEL, and SPRING-FREEWHEEL components. Additional elements like RING-SNAP, RING-RETAINING, and RETAINER provide secure component retention, and the ADAPTER-DRIVE and COUPLINGAS ensure proper power transfer interfaces. The entire assembly is housed within the HOUSINGAS and includes PLATE-SIDE and PLATE-SPLINED components for structural integrity, with PLUG-LDSTOR providing access points for maintenance.
- Every aspect of the SANY TCGP-BASIC demonstrates meticulous engineering precision, ensuring reliable performance and longevity in the most demanding operating conditions, reflecting SANY’s commitment to transmission excellence.
Parameters of SANY Tcgp-Basic
| No. | Part No. | Description | Qty |
| 1 | 130202000093A272 | RING-SNAP | 3 |
| 2 | 130202000093A273 | PLATE-SIDE | 2 |
| 3 | 130202000093A274 | ADAPTER-DRIVE | 1 |
| 4 | 130202000093A275 | SEAL-O-RINGO | 1 |
| 5 | 130202000093A276 | IMPELLER | 1 |
| 6 | 130202000093A277 | DOWEL | 2 |
| 7 | 130202000093A278 | RING-RETAINING | 1 |
| 8 | 130202000093A279 | HUB-IMPELLER | 1 |
| 9 | 130202000093A280 | WASHER-HARD | 8 |
| 10 | 130202000093A281 | BOLT-SOCKETHEAD | 8 |
| 11 | 130202000093A282 | RACE-BRGTHRUST | 3 |
| 12 | 130202000093A283 | BEARING-THRUST | 2 |
| 13 | 130202000093A284 | CARRIER-STATOR | 1 |
| 14 | 130202000093A285 | BEARING-THRUST | 2 |
| 15 | 130202000093A286 | STATOR-CONVERTER | 1 |
| 16 | 130288000778A | COUPLINGAS | 1 |
| 17 | 130202000093A287 | BOLT-HEXHEAD | 20 |
| 18 | 130202000093A288 | RING-SEALMETAL | 1 |
| 19 | 130202000093A289 | RETAINER | 1 |
| 20 | 130202000093A290 | SEAL-ORINGO | 1 |
| 21 | 130202000093A291 | PLUG-LDSTOR | 1 |
| 22 | 130202000093A292 | BOLT-HEXSOCKET | 1 |
| 23 | 130202000093A293 | BOLT | 24 |
| 24 | 130202000093A038 | Washer | 24 |
| 25 | 130202000093A294 | HOUSINGAS | 1 |
| 26 | 130202000093A295 | RING-SEAL | 1 |
| 27 | 130202000093A296 | PISTON-CLUTCH | 1 |
| 28 | 130202000093A297 | RING-SEAL | 1 |
| 29 | 130202000093A298 | SEAL-O-RINGO | 3 |
| 30 | 130202000093A299 | PLATE-SPLINED | 1 |
| 31 | 130202000093A300 | PLATE | 2 |
| 32 | 130202000093A301 | DISC-FRICTION | 2 |
| 33 | 130202000093A302 | PLATE-BACKING | 1 |
| 34 | 130202000093A303 | TURBINE | 1 |
| 35 | 130202000093A304 | HUB-TURBINE | 1 |
| 36 | 130202000093A305 | RACE-THRUST | 1 |
| 37 | 130202000093A306 | CAM-FREEWHEEL | 1 |
| 38 | 130202000093A307 | ROLLER-FREEWHEEL | 11 |
| 39 | 130202000093A308 | SPRING-FREEWHEEL | 11 |
