What is the SANY System-Oil Supply

  • The SANY System-Oil Supply represents a meticulously engineered fuel management solution designed to ensure reliable and efficient power delivery in SANY machinery. This comprehensive system integrates precision components that work in harmony to maintain consistent fuel flow, filtration, and circulation, supporting optimal engine performance and longevity in demanding operating conditions.
  • At the heart of the system lies the robust Tank, fuel, which provides secure fuel storage, complemented by the Hoop reinforcement that ensures structural integrity. The Annular joint, manual fuel pump facilitates secure connections for manual priming operations, while the Oil intake pipe, diesel filter and Pipe, oil inlet, engine work in concert to deliver clean fuel to the engine. The return circuit is managed through the Pipe, oil return and Connector, oil return, completing the fuel circulation pathway.
  • The system’s connectivity is enhanced by specialized components including the Joint, oil intake and Connector, tee, which enable precise routing and distribution of fuel. Secure fastening is achieved through multiple Nut and Bolt elements, particularly the Bolt, link for critical connections, while numerous Washer components ensure leak-proof seals and proper load distribution throughout the assembly. Each element within the SANY System-Oil Supply is manufactured to exacting standards, ensuring durability and reliability while maintaining efficient fuel delivery under varying operational conditions. The precision engineering behind the SANY System-Oil Supply demonstrates SANY’s commitment to operational efficiency and mechanical excellence through carefully designed fluid management systems.

Parameters of SANY System-Oil Supply

Item No. Part No. Description Qty.
1 A210401000001 Nut 2
2 A210405000011 Washer 2
3 A210401000002 Washer 12
4 A210405000001 Washer 12
5 A210434000007 Washer 4
6 A210434000008 Washer 1
7 A210434000009 Washer 1
8 A229900007586 Annular joint, manual fuel pump 2
9 60036348 Tank, fuel 1
10 A210855000003 Hoop 8
11 A210319000001 Nut 2
12 A210111000018 Bolt 2
13 A210307000001 Nut 12
14 A210111000040 Bolt 12
15 A210459000007 Bolt, link 2
16 10126538 Oil intake pipe, diesel filter 1
17 10126540 Pipe, oil inlet, engine 1
18 10126541 Pipe, oil return 1
19 10178417 Joint, oil intake 1
20 10178418 Connector, oil return 1
21 11767937 Connector, tee 1
