Sany Piping-Steering

Sany Parts engineering delivers complete hydraulic circuit solutions for heavy machinery. The Sany Piping-Steering is a fully integrated steering fluid network for excavators, loaders, mining trucks, and cranes. This Sany Piping-Steering combines a steering reservoir, cooling pipe, rubber hoses, steel pipes, adaptors, connectors, hoops, joints, and fasteners. Every component ensures leak-free fluid transfer and responsive steering. Upgrade your fleet with a genuine Sany Piping-Steering.

The Sany Piping-Steering is a factory-engineered hydraulic circuit network for Sany excavators, loaders, mining trucks, and crawler cranes. It delivers pressurized steering fluid from pump to steering gear and back to reservoir. This advanced Sany Piping-Steering integrates a steering reservoir assembly (A810299019000) that maintains proper fluid levels and conditioning for consistent steering performance.

The system includes a cooling pipe assembly (60020493) that maintains optimal hydraulic fluid temperature during continuous heavy operation. Multiple hose types work together: generic rubber hoses (B230103000278, B230103004501, B230103004504) and a specialized 1SN12 hose (B230103000283) with DKOL crimped end fittings rated for high-pressure applications up to 320 bar.

Rigid fluid pathways use steel pipe assemblies (10016671 and 10016669) precisely bent for optimal chassis routing. A tube adaptor (A229900002499) and pipe connector (A229900002820) provide sealed interfaces between flexible and rigid line sections. A ring hose hoop (A229900002965) and a precision joint (A229900006314) ensure firm retention.

An oil inlet hose (10999387) delivers fluid from reservoir to steering pump. Secure connections use high-strength nut (A210319000001) and bolt (A210111000025) fasteners, ensuring leak-free performance under high pressure and vibration. The system meets ISO 1219 and SAE J517 standards.

Originally OEM on SY excavators, SW loaders, SKT trucks, and STC cranes, the Sany Piping-Steering is available as a complete replacement assembly through the genuine parts network spanning 120+ countries. The modular design allows independent replacement of any component group.

All 15 Part Numbers are traceable through certified channels. Backed by a 24‑month warranty, this steering hydraulic circuit ensures responsive control and leak‑free integrity. Each assembly is factory pressure‑tested before shipment.

Daily Visual Inspection of Hoses and Reservoir Level: Before each shift, check the steering reservoir (A810299019000) fluid level (engine off, level ground). Level must be between Full and Low. Inspect all four rubber hoses (B230103000278, B230103000283, B230103004501, B230103004504) for cracks, bulges, or wet spots. Pay special attention to the 1SN12 high-pressure hose and oil inlet hose (10999387) connections. Look for weeping around adaptor and pipe connector seals. Any leak must be repaired immediately.

Cooling Pipe and Steel Tube Integrity Check: Every 250 hours, inspect the cooling pipe assembly (60020493) for damage, corrosion, or impact. The spiral pipe must show no kinking or flattening. Examine both steel pipe assemblies (10016671 and 10016669) for bending, cracking, or surface corrosion. Ensure adaptor (A229900002499) and joint (A229900006314) are secure. Clean debris from cooling pipe surfaces to maintain heat transfer efficiency.

Hose Clamp Torque and Fastener Verification: Every 500 hours, verify all fasteners with a calibrated torque wrench. Tighten nut (A210319000001) and bolt (A210111000025) to Sany specs: 25-35 Nm (M6) or 45-60 Nm (M8). Inspect ring hose hoop (A229900002965) for proper seating. Replace any corroded fastener. After service, cycle steering lock-to-lock and re-inspect joints for seepage.

Fluid Change and Hydraulic System Flushing: Every 2,000 hours, drain and replace steering hydraulic fluid. Inspect drained fluid for metallic particles or dark discoloration—indicates internal wear. Replace filter element inside steering reservoir. Flush cooling pipe (60020493) and steel pipes with clean fluid. After refilling, run engine at idle and turn steering wheel lock-to-lock at least 15 times to bleed air. Recheck fluid level.

Annual Full System Pressure Test and Hose Replacement: Every 4,000 hours, have a certified technician perform hydraulic pressure test on entire circuit. Replace any hose showing external cracking or over 5,000 service hours—especially the 1SN12 hose (B230103000283) and oil inlet hose (10999387). Replace adaptor O‑rings and pipe connector seals when replacing hoses. This schedule extends service life and ensures leak‑free steering control.
