SANY Pipe GP-Return & Suction-Chassis
What is the SANY Pipe GP-Return & Suction-Chassis
- The SANY Pipe GP-Return & Suction-Chassis constitutes a sophisticated hydraulic management system specifically engineered for efficient fluid transfer in heavy machinery applications. This comprehensive assembly features multiple Pipe, rubber, oil suction components and a robust Thick pipe GP, oil suction that work in coordination to ensure optimal fluid flow between system components. The system is powered by a precision Oil pump GP, which drives hydraulic circulation through an extensive network of connections.
- The configuration incorporates various Hose, rubber elements and specialized Hose connections that provide essential flexibility and vibration resistance, while the critical Oil Return Steel Pipe Assy.SYM5331JB.7.1 ensures reliable fluid return operations. Secure connections are maintained through multiple Flange, split assemblies with O-ring seals, complemented by numerous Connector, pipe fittings that ensure leak-free performance under high-pressure conditions.
- The entire assembly is firmly secured using high-strength Bolt fasteners with Washer and Nut components, while Hoop, ring, dual-wire and Clamp, pipe, single section provide additional structural support and vibration resistance. A dedicated Plug element allows for maintenance access and system bleeding when required. Each component within the SANY Pipe GP-Return & Suction-Chassis is meticulously engineered to withstand extreme operational stresses, ensuring consistent performance and reliability in demanding working environments.
- This integrated system demonstrates SANY’s commitment to hydraulic excellence, featuring superior materials and precision manufacturing that contribute to extended service life and reduced maintenance requirements. The advanced design of the SANY Pipe GP-Return & Suction-Chassis ensures optimal hydraulic efficiency and operational reliability, reflecting SANY’s dedication to engineering quality and performance excellence in heavy equipment systems. The careful integration of these components creates a seamless hydraulic circuit that maintains peak performance under the most challenging conditions, showcasing SANY’s innovation in hydraulic system design.
Parameters of SANY Pipe GP-Return & Suction-Chassis
| Item No. | Part No. | Description | Qty. |
| 1 | 11676718 | Pipe, rubber, oil suction | 1 |
| 2 | A210110000228 | Bolt | 4 |
| 3 | A210401000003 | Washer | 4 |
| 4 | A210444000001 | Washer | 4 |
| 5 | A210307000025 | Nut | 4 |
| 6 | A210855000037 | Hoop, ring, dual-wire | 8 |
| 7 | 00001487 | Oil pump GP | 1 |
| 8 | 10878799 | Pipe, rubber, oil suction | 1 |
| 9 | A810201029364 | Thick pipe GP, oil suction | 1 |
| 10 | B230103008039 | Hose, rubber | 1 |
| 11 | B230103004200 | Hose, rubber | 1 |
| 12 | B230103008038 | Hose, rubber | 1 |
| 13 | B229900000333 | Flange, split | 2 |
| 14 | A210111000041 | Bolt | 4 |
| 15 | B230101000215 | O-ring | 1 |
| 16 | A229900002509 | Flange, split | 2 |
| 17 | A210111000039 | Bolt | 4 |
| 18 | B230101000244 | O-ring | 1 |
| 19 | 60016569 | Hose | 1 |
| 20 | 21008677 | Connector, pipe | 2 |
| 21 | A210111000023 | Bolt | 8 |
| 22 | A229900002489 | Flange, split | 4 |
| Item No. | Part No. | Description | Qty. |
| 23 | B230101000580 | O-ring | 2 |
| 24 | B230103003223 | Hose, rubber | 1 |
| 25 | A229900002561 | Connector, pipe | 1 |
| 26 | B230103004686 | Hose, rubber | 1 |
| 27 | B230103001001 | Hose | 1 |
| 28 | 12665784 | Oil Return Steel Pipe Assy.SYM5331JB.7.1 | 1 |
| 29 | A229900002424 | Clamp, pipe, single section | 2 |
| 30 | A229900002547 | Plug | 1 |
| 31 | B230103004188 | Hose, rubber | 1 |
| 32 | A210111000023 | Bolt | 4 |
| 33 | A229900002510 | Connector, pipe | 1 |
| 34 | A229900002525 | Connector, pipe | 2 |
