SANY Housinggp-Tc
What is the SANY Housinggp-Tc
- The SANY HOUSINGGP-TC represents the central housing assembly for SANY’s torque converter system, engineered to exceptional precision standards for reliable power transmission in heavy machinery applications. This comprehensive assembly incorporates the main HOUSINGAS-TC structure which serves as the foundational element containing all critical components. The system features advanced bearing arrangements with CUP-SPLTAPERED and CONE-SPLTAPERED tapered roller bearings, complemented by CUP-ROLLERBRG and CONE-ROLLERBRG roller bearing components that ensure smooth rotational operation and load management.
- The SANY HOUSINGGP-TC utilizes multiple sealing solutions including SEAL-LIPTYPE lip seals, RING-SEAL sealing rings, and numerous SEAL-O-RINGO O-ring seals throughout the assembly, providing complete fluid containment and environmental protection. Fastening systems incorporate BOLT-HEXHEAD and BOLT-SOCKETHEAD bolts with WASHER-HARD and standard Washer components, along with NUT-HEX and LOCK-NUT elements for secure, vibration-resistant connections. The STUD-STRAIGHT provides additional mounting stability.
- The SANY HOUSINGGP-TC integrates power transmission elements including GEAR components and CARRIERAS gear carriers, while the BEARING-THRUST manages axial loads. The retarder system features STATOR-RETARDER and ROTOR-RETARDER components for auxiliary braking functionality. The assembly includes MANIFOLD components for fluid distribution, BREATHERAS for pressure equalization, and PLUG-LDSTOR for maintenance access. RING-RETAINING and SHIELDAS components provide additional protection and retention, while GASKET elements ensure perfect sealing between mating surfaces.
- Every aspect of the SANY HOUSINGGP-TC demonstrates superior engineering quality, ensuring reliable performance and extended service life in the most demanding operating conditions, reflecting SANY’s commitment to excellence in power transmission technology.
Parameters of SANY Housinggp-Tc
| No. | Part No. | Description | Qty |
| 1 | 130202000093A309 | CUP-SPLTAPERED | 2 |
| 2 | 130202000093A310 | CONE-SPLTAPERED | 2 |
| 3 | 130202000093A311 | RING-RETAINING | 1 |
| 4 | 130202000093A312 | RING-SEAL | 1 |
| 5 | 130202000093A313 | SEAL-LIPTYPE | 1 |
| 6 | 130202000093A314 | STUD-STRAIGHT | 8 |
| 7 | 130202000093A038 | Washer | 14 |
| 8 | 130202000093A315 | NUT-HEX | 8 |
| 9 | 130202000093A028 | BREATHERAS | 1 |
| 10 | 130202000093A316 | BOLT-HEXHEAD | 5 |
| 11 | 130202000093A317 | HOUSINGAS-TC | 1 |
| 12 | 130202000093A027 | SEAL-O-RINGO | 1 |
| 13 | 130202000093A318 | SEAL-O-RINGO | 1 |
| 14 | 130202000093A319 | CARRIERAS | 1 |
| 15 | 130202000093A320 | GEAR | 1 |
| 16 | 130202000093A321 | CONE-ROLLERBRG | 1 |
| 17 | 130202000093A322 | GEAR | 1 |
| 18 | 130202000093A323 | SHIELDAS | 1 |
| 19 | 130202000093A324 | CUP-ROLLERBRG | 1 |
| 20 | 130202000093A325 | CUP-RLRBEARING | 1 |
| 21 | 130202000093A326 | CONE-RLRBEARING | 1 |
| 22 | 130202000093A327 | LOCK-NUT | 1 |
| 23 | 130202000093A328 | BEARING-THRUST | 1 |
| 24 | 130202000093A329 | GASKET | 1 |
| 25 | A210405000011 | WASHER-HARD | 14 |
| 26 | 130202000093A330 | BOLT-SOCKETHEAD | 13 |
| 27 | 130202000093A331 | STATOR-RETARDER | 1 |
| 28 | 130202000093A332 | RING-SEAL | 2 |
| 29 | 130202000093A333 | ROTOR-RETARDER | 1 |
| 30 | 130202000093A334 | STATOR-RETARDER | 1 |
| 31 | 130202000093A335 | WASHER-HARD | 4 |
| 32 | 130202000093A336 | BOLT-HEXHEAD | 2 |
| 33 | 130202000093A337 | PLUG-LDSTOR | 1 |
| 34 | 130202000093A338 | SEAL-O-RINGO | 1 |
| 35 | 130202000093A339 | HOUSINGAS | 1 |
| 36 | 130202000093A340 | NUT-BEARINGLOCK | 1 |
| 37 | 130202000093A341 | SEAL-O-RINGO | 2 |
| 38 | 130202000093A342 | MANIFOLD | 1 |
| 39 | 130202000093A343 | BOLT-HEXHEAD | 2 |
| 40 | 130202000093A344 | WASHER-HARD | 20 |
| 41 | 130202000093A345 | BOLT-HEXHEAD | 13 |
| 42 | 130202000093A346 | BOLT-HEXHEAD | 1 |
| 43 | 130202000093A347 | RACE-OUTER | 1 |
| 44 | 130202000093A348 | BOLT-HEXHEAD | 7 |
| 45 | 130202000093A060 | MANIFOLD | 1 |
