OEM 61021264 Rubber Gripper Clip – Genuine SANY Cable Retention Component

The genuine SANY parts reference 61021264 is the Clip, Gripper, Rubber, a precision‑engineered fastening component designed to securely retain wiring harnesses, cables, and hoses in SANY heavy‑duty trucks, excavators, and construction machinery. The 61021264 rubber gripper clip provides a soft, vibration‑damping grip that prevents chafing, reduces noise, and protects insulation from abrasion.

Manufactured from high‑grade elastomer with an integral metal or plastic mounting base, the 61021264 clip delivers exceptional retention force, weather resistance, and long‑term durability in harsh engine compartments. Each 61021264 unit is 100% inspected for dimensional accuracy, material hardness, and grip strength, guaranteeing reliable cable management in SRT dump trucks, SY excavators, SW wheel loaders, and motor graders.

As an essential component of the SANY Electrical System Group, the 61021264 Clip, Gripper, Rubber is used to bundle and route wire harnesses along engine blocks, chassis frames, and hydraulic lines. The rubber construction cushions the retained item against vibration, while the gripper design accommodates a range of cable diameters without slipping. The clip typically features a push‑in or screw‑mount base that attaches to pre‑drilled holes or studs, and a flexible rubber loop that wraps around the bundle.

The 61021264 rubber gripper clip is engineered to withstand engine compartment temperatures from -40°C to +120°C and resist oil, fuel, and coolant exposure. Each 61021264 unit is 100% inspected for grip force, tear strength, and mounting compatibility, guaranteeing reliable performance in the most demanding mining, construction, and material handling environments.

Clip, Gripper, Rubber

Резиновый фиксатор

Clip de sujeción de goma

Material and Design of Rubber Gripper Clip 61021264

The rubber gripper clip 61021264 is manufactured from high‑grade synthetic elastomer, typically EPDM (ethylene propylene diene monomer) or chloroprene (CR) rubber, chosen for its excellent resistance to heat, oil, ozone, and weathering. The rubber formulation provides a Shore A hardness of 60‑75, offering sufficient flexibility to wrap around cable bundles while maintaining secure retention force. The clip is molded as a one‑ or two‑piece design with an integrated mounting base made of steel or reinforced plastic. The base includes a hole or stud for attachment to the vehicle structure.

The gripper geometry of the 61021264 clip features a curved inner profile that conforms to the shape of the harness, with optional ribbed contact surfaces to increase friction and prevent axial slippage. The clip’s retention force is calibrated to hold the bundle firmly under vibration but allow service removal without tools. The rubber material also acts as a dielectric insulator, preventing chafing that could lead to short circuits. The mounting base is typically zinc‑plated steel for corrosion resistance, and the rubber is bonded to the base through a vulcanization process to ensure permanent attachment.

All 61021264 rubber gripper clips are 100% inspected for critical dimensions: inner diameter at rest, gripping force at specified bundle size, and tear strength. Each clip is tested for oil immersion resistance (168 hours at 100°C) and low‑temperature flexibility (-40°C). A batch code is molded into the rubber or stamped on the metal base, providing full traceability to the compound mix, molding parameters, and final inspection records.

Integration Within the SANY Electrical System Group

The rubber gripper clip 61021264 is a key component of the SANY Electrical System Group, which manages the complex network of wiring that connects the engine control unit (ECU), sensors, injectors, and actuators. The clip secures harnesses along the engine, frame, and cab, preventing wires from contacting hot surfaces, moving parts, or sharp edges. It is often used in conjunction with plastic cable ties, clamps, and adhesive‑backed mounts to create a complete retention system.

In a typical SANY engine, the 61021264 clip is installed at regular intervals along the main engine harness, securing bundles to pre‑welded studs or drilled holes on the cylinder head, intake manifold, or chassis rail. The rubber cushion isolates the harness from vibration, reducing fatigue on individual wires and connectors. The clip’s quick‑release feature allows service technicians to temporarily free a harness for access without cutting ties or removing fasteners.

Using genuine SANY rubber gripper clips ensures correct fitment to the specific stud diameter and hole spacing of the vehicle. Aftermarket clips may have incorrect rubber hardness, leading to loose retention or harness damage. The 61021264 clip is also compatible with standard wiring harnesses and can be reused multiple times if not damaged.

Machine Compatibility & Critical Applications

The rubber gripper clip 61021264 is used in SANY D09 and D12 series diesel engines and across the electrical systems of SRT dump trucks (SRT45, SRT55, SRT95, SRT115), wheel loaders (SW405, SW435, SW465, SW305), crawler excavators (SY215, SY335, SY395, SY500), and motor graders (SMG200, SMG220). It is also installed on SANY concrete pump trucks, crawler cranes, and heavy forklifts.

Typical applications include securing the engine harness along the cylinder head, bundling injector wiring, routing sensor cables to the ECU, and organizing hoses in hydraulic systems. The rubber clip is also used to retain air conditioning lines, fuel hoses, and coolant hoses where vibration damping is required. Its ability to grip a range of diameters makes it ideal for holding irregular bundles.

The D09 engine is a straight‑6 diesel with 8.7 liters displacement, 117 mm bore, 135 mm stroke, producing 280‑380 HP and 1,500 N·m of torque. The D12 engine offers 12.13 liters displacement, 131 mm bore, 150 mm stroke, with torque reaching 700 N·m. Both engines utilize SANY’s patented TOP‑Down cooling system and split‑type cylinder head. The rubber gripper clip must withstand engine bay temperatures up to 120°C and exposure to oil and coolant.

For complete electrical system reliability, the 61021264 clip should be replaced if the rubber shows cracking, hardening, or loss of elasticity. When servicing, always inspect the mounting base for corrosion and replace any damaged clips with new genuine SANY units. Use the correct size clip for the bundle diameter – oversizing will cause loose retention, undersizing may over‑compress the wires.

Technical Specifications – Clip, Gripper, Rubber 61021264

Proper Installation of Rubber Gripper Clip 61021264

When installing the rubber gripper clip 61021264, first clean the mounting surface and the stud or hole. Ensure that the rubber is free of cuts, tears, or hardening. For push‑on stud types, align the rubber hole with the stud and press firmly until the clip seats fully. For screw‑mount versions, position the clip over the hole and insert the mounting screw; torque to 2‑4 N·m (do not over‑tighten). Then gather the wiring harness or hose bundle and press it into the rubber gripper loop. The clip should hold the bundle snugly without compressing individual wires excessively.

If the clip is of the two‑piece design (with a removable strap), first mount the base, then place the harness in the cradle, and finally snap the rubber strap over the top. Ensure that the strap locks securely. For multiple bundles, use separate clips or a larger clip rated for the combined diameter. Do not force an oversize bundle into a clip designed for smaller diameters, as this can permanently deform the rubber and reduce retention.

After installation, tug gently on the harness to verify that it is secure but not overly tight. The harness should not slide axially under moderate force, but the clip should allow slight rotation to prevent strain. If the clip is loose, inspect for correct sizing or replace with a new clip. Never reuse a clip that has been stretched or has visible cracks.

Always replace rubber gripper clips when the rubber shows signs of aging (hardening, cracking, loss of elasticity). Use genuine SANY clips to ensure correct rubber compound and retention force. Store new clips in a cool, dry place away from direct sunlight and ozone sources.

Symptoms of Failed Rubber Gripper Clip

A failed rubber gripper clip 61021264 can cause several issues. Visible sagging or movement of the wiring harness indicates that the clip has lost retention force. The harness may contact hot engine surfaces, causing insulation melting, short circuits, or even fires. Chafing marks on the harness where the rubber has hardened or worn through may expose bare wires.

If the clip’s mounting base is corroded or broken, the clip may detach from the vehicle, leaving the harness unsupported. This can lead to excessive vibration, fatigue failure of wires, and intermittent electrical faults such as check engine lights or sensor dropouts. A broken rubber loop may allow the harness to fall onto moving parts like fan belts or pulleys, causing immediate damage.

During routine maintenance, inspect each rubber gripper clip for cracks, hardening, or stretching. If the rubber feels brittle or shows surface cracking, replace the clip. Also check the metal base for rust or deformation. Replace any damaged clip with a new genuine SANY 61021264 clip.

Quality Assurance & Full Traceability

Every rubber gripper clip 61021264 is manufactured in an IATF 16949 certified facility under SANY’s rigorous quality management system. The production process includes raw material compound verification, in‑process dimensional checks using vision systems, and 100% inspection of critical features including inner diameter, grip force, and base integrity. A sample from each batch is subjected to oil immersion tests, ozone resistance tests, and low‑temperature flexibility tests (-40°C).

A batch code is molded into the rubber or printed on the packaging, providing full traceability to the compound mix date, molding parameters, and final inspection records. For bulk orders, a Certificate of Conformance (CoC) is provided, certifying that the clips meet all SANY OEM specifications for material, dimensions, and performance.

Independent third‑party audits ensure continuous compliance with ISO 9001:2015 and IATF 16949 standards.

Field Performance of Genuine SANY Rubber Gripper Clip

Field data from SANY dump trucks and excavators operating in Australian iron ore mines and South African quarries shows that genuine 61021264 rubber gripper clips maintain their elasticity and retention force for the full engine service interval, typically exceeding 20,000 operating hours. Aftermarket clips often fail prematurely due to inferior rubber compounds, incorrect hardness, or poor bond to the metal base, leading to loose harnesses and electrical faults within 5,000‑8,000 hours.

The superior durability of the genuine SANY clip comes from the premium EPDM or chloroprene rubber, the precise molding that ensures consistent grip geometry, and the vulcanized bond that prevents separation of rubber from the base. Fleet owners report that standardizing on genuine SANY clips eliminates intermittent electrical faults and reduces harness repair costs.

To maximize service life, always replace rubber gripper clips when the rubber shows signs of aging. Use genuine SANY clips to ensure correct fit and material. During installation, avoid over‑stretching the rubber and ensure that the clip is properly seated on the mounting stud. Following these practices ensures reliable cable management and long equipment life.
