SANY Corehole Plug 60272566 – OEM Sealing for D12/D09 Engine Blocks

Corehole Plug

Заглушка технологического отверстия

Tapón de orificio de núcleo

The 60272566 Corehole Plug is a precision sealing component within the SANY Engine Block Group. According to the SANY Engine Block Group parts catalog, this plug is listed alongside other critical components such as the Pressure and Temperature Sensor (160102130004A025), Cylinder Liner units, Hexagon Flange Bolts (1001675556 1), O‑ring seals, and Assembled Sealing Washers. Together, these components form the foundation of SANY’s heavy‑duty diesel engines used globally in construction, mining, and transport equipment.

The 60272566 is specifically used to seal the core holes left in the engine block during the casting process, preventing engine oil and coolant from leaking out of the block. The SANY D12 engine, jointly developed with DEUTZ, has a displacement of 12.12 liters and six cylinders. It delivers 360 kW (490 hp) at 1,900‑2,100 rpm, with a maximum torque of 2,150 Nm.

This high‑output engine requires an exceptionally robust sealing system to prevent fluid leaks. The 60272566 plug is part of that system, ensuring that oil galleries and coolant passages remain sealed under peak cylinder pressures. The D12 engine meets Euro VI emission regulations through its 1,800 bar common‑rail injection system. Its low idle speed of 525 rpm reduces component wear and extends service life.

The 60272566 corehole plug works in conjunction with other sealing elements including Corehole plug 16/10 (61000765), Pulling Rivet (160102120008A009), Hexagon Screw Plug (160102120008A007), and Plug, Threaded, Socket Head Cap (60272464) to ensure complete leak‑proof sealing of all machining passages and fluid galleries. Together, these components form an integrated sealing system that delivers uncompromising reliability.

The 60272566 corehole plug is manufactured from high‑quality materials that resist thermal fatigue, corrosion, and compression set. The plug’s sealing action relies on its concave shape, which expands outward when driven into the core hole, creating a tight interference fit that prevents fluid migration under pressure. This type of expansion plug is also known as a Welch plug or cup plug.

It is widely used in water‑cooled internal combustion engines to seal the openings left by sand casting cores. The plug is installed with the convex side outward, and when struck with a suitable tool, it flattens and expands radially, creating a permanent seal. The D12 engine has been widely applied in SANY truck mixers, dump trucks, truck‑mounted pumps, compact rollers, excavators, port machinery, and ultra‑high‑pressure pumps.

Wherever these engines operate, the reliability of every fluid joint depends on using genuine SANY sealing components. Aftermarket corehole plugs may have incorrect diameter tolerances or be made from inferior materials that corrode or loosen over time. Using the genuine 60272566 ensures proper fitment, consistent sealing force, and resistance to engine oil, coolant additives, and combustion byproducts.

Why the 60272566 Corehole Plug Ensures Leak‑Free Engine Operation

Technical Specifications – Corehole Plug 60272566

Installation of the 60272566 corehole plug must be performed with clean surfaces. Thoroughly clean the inside of the core hole. Remove any old sealer, corrosion, or debris. Lightly coat the inside of the core hole with Loctite Stud N’ Bearing Mount or equivalent anaerobic sealant as specified in the SANY service manual.

Position the 60272566 plug with the convex side facing outward (the concave side faces the fluid passage). Using a suitable driver that contacts only the outer perimeter, tap the plug squarely into the hole until it is flush with the surrounding casting. Then, strike the centre with a drift to flatten the plug, expanding it radially to create the permanent seal.

Common installation errors include: using the wrong size plug, failing to clean the hole, driving the plug too deep, striking off‑centre, or using excessive force. A correctly installed plug will be firmly seated and resistant to movement. After installation, pressure‑test the cooling system and oil galleries to verify no leakage.

For SANY equipment operating in severe conditions such as mining, desert environments, or high‑altitude regions, inspect the corehole plugs for signs of corrosion or leakage at every scheduled service. If coolant is weeping from a plug, replace it immediately. Replace all corehole plugs at major engine overhaul (10,000‑12,000 hours) as a preventive measure.

Applications of Corehole Plug 60272566

To verify authenticity, inspect the 60272566 corehole plug for the SANY logo and part number stamped on the plug flange. Genuine SANY plugs have a consistent cup shape with a smooth surface. Aftermarket plugs often lack markings or have rough finishes. Always source from authorised SANY parts distributors to ensure warranty coverage and reliability.

When ordering, provide your engine serial number (ESN). The 60272566 is part of the SANY Engine Block Group and is used as a dedicated sealing element for core holes on D12 and D09 engines. Two of these plugs are required per engine. Purchase two plugs to complete a full engine overhaul.
