160102130004A069 SANY Fuel Injection Pump Group – Precision Fuel Delivery for Heavy Duty

Ultimate injection precision for SANY diesel engines. The 160102130004A069 Fuel Injection Pump Group is a heavy-duty, high-pressure unit engineered to optimize combustion efficiency and power delivery. As a cornerstone of modern fuel systems, this OEM-grade component meets the strictest emissions standards. Trusted globally, SANY parts guarantee consistent fuel metering and extended engine life. With OE number 160102130004A069, this injection pump group ensures rapid pressure build-up for large-displacement engines, reducing fuel consumption and cold-start smoke. Built for SANY excavators, loaders, and heavy trucks, it provides wear-resistant plungers and an integrated governor system that surpasses aftermarket alternatives.

The 160102130004A069 Fuel Injection Pump Group is a precision rotary pump designed for SANY’s Euro Stage V / Tier 4 Final engines. It integrates a high-pressure supply pump with an advanced electronic governance module, delivering injection pressures up to 2200 bar. This ensures complete atomization of diesel fuel, reducing particulate emissions and improving fuel economy by up to 7% compared to conventional pumps. The complete pump group includes the transfer pump, plunger barrel assembly, delivery valves, and a robust camshaft with roller tappets.

Each unit bearing the OEM code 160102130004A069 undergoes 100% hydraulic leak test and performance mapping on a test bench. It is a direct replacement for SANY SY235, SY335, SY485H excavators, as well as SW405K wheel loaders and STC series cranes. The plunger diameter of 9.5mm and cam lift of 12mm provide outstanding fuel volume delivery for engines up to 15 liters displacement.

The injection pump group 160102130004A069 is validated for direct fitment on SANY SY215C-9, SY335H-10, SY485H-10 excavators; SW405K, SW955K wheel loaders; and SANY STC250E, STC800T5 truck cranes. It also matches SANY mining rigid dump trucks SRT55D and SRT95C equipped with Cummins QSM11 or ISM engines using SANY fuel system architecture. When replacing, always cross-reference the OEM number 160102130004A069 to guarantee correct plunger stroke and housing orientation.

For fleet managers, using genuine SANY-compatible injection pump groups maintains emission compliance and avoids ECU fault codes (P0216, P0251). The pump group includes a new mounting kit with sealing rings and banjo bolts.

• Cleanliness is critical: Flush fuel lines before mounting the 160102130004A069 pump to prevent dirt ingress.
• Timing alignment: Align the pump flange marks with engine top dead center (TDC) according to SANY service manual.
• Torque specifications: Mounting bolts 45 Nm; high-pressure line nuts 25 Nm. Use new copper washers.
• Electronic calibration: Perform pump learning routine using SANY diagnostic tool after installation to adapt fuel trim values.
• Service interval: Replace injection pump group every 10,000 hours or when delivery deviation exceeds ±5% during injector balancing test.

Always prime the low-pressure circuit before cranking. Failure to prime may damage the 160102130004A069 unit due to dry running. Use a hand primer to fill the pump with clean diesel.

The 160102130004A069 Fuel Injection Pump Group has undergone 3,000 hours of endurance testing on a dynamometer with varying loads from 30% to 110% rated power. No plunger scuffing or leakage occurred. High-cycle fatigue test (2×10⁷ cycles) confirmed camshaft reliability. In field trials with 25 SANY SY335H machines operating in Mongolian mining sites, the pump showed less than 2% flow degradation after 8,500 hours, outperforming non-OE alternatives by 40%.

Additionally, the pump group is certified to withstand extreme fuel temperatures (-35°C to 85°C) and vibration levels up to 12g rms (10-2000 Hz), meeting ISO 1940 balancing grade G2.5. This makes 160102130004A069 the ideal choice for off-road construction and mining applications where reliability is paramount.

Counterfeit injection pumps often use substandard alloys and incorrect governor springs, leading to unstable idle and high smoke opacity. The OEM 160102130004A069 group is manufactured under ISO 9001:2025 with 100% end-of-line performance mapping using Bosch common rail test equipment. Each pump is marked with laser-etched SANY logo and full part number for traceability.

Choosing genuine SANY parts directly reduces total cost of ownership: better fuel efficiency, fewer DPF clogging events, and longer injector life. With a global network of SANY service centers supporting this part, you ensure maximum uptime for your heavy equipment. Upgrade to the 160102130004A069 Fuel Injection Pump Group and experience the difference of precision engineering.
